EVA Foam Filled Fender With High Performance And ISO Certificate
►CCS authorization marine foam filled eva foam fender buoy
Henger polyurethane Eva foam filled fender made of high quality high density Eva
foam and new formulations to coating polyurea ,so the eva foam filled fender is have
beautiful colors and very durable.
1. Inner:We use high density closed cell eva foam, do not absorb water and have big buoyancy
2. Outer:We coating high quality polyurea elastomer outside , the surface is bright and clean and have certain elasticity
3. At both ends: For small polyurethane eva foam fender can use rope hanging on both sides. For Large eva foam fender will use rings or flange for connection.
4. Shape: we can make customer size, shape and color;also can make rope net or tyre-chain net outside to protect the fender body.
5. Long life span
6. qualified products delivery after testing
►EVA Filled Foam Fender Introductions
Foam filled fender,also called EVA solid fender, is a new type fender using light weight high elasticity foam as cushion medium, widely applied to harbour, offshore,STS and STD operation. Henger Foam Filled Solid Fender is made of environmental protection material and high elasticity polymeric material. long service life and high economic value of this product is achieved by the high quality material with performance of high strength, high elasticity, high adhesion, anti-leakage,and aging resistance.
►Company introduction
Qingdao Henger Shipping Supplies Co., Ltd
Lies in Qingdao, a beautiful coastal city.Qingdao Henger Shipping Supplies Co., Ltd is a high tech enterprise integratewith manufacturing, research andinnovation, technical services, specialized in manufacturing marine products,such as pneumatic rubber fenders, foam filled fenders, marine rubber airbags,navigation mark, marine buoys, highway safety roller barrier. All products get ISO 9001-2008 certificate and IACS quality authentication from CCS, BV, GL, ABS, LG, etc.With strong technology base, advanced manufacturing technique, complete manufacturing facilities and well-equipped checkout equipment, Qingdao Henger Shipping Supplies Co., Ltd is devoted to forge itself into a top-ranking international competitive marine products manufacturer providing high qualityproducts and perfect service for all customers, and shoulder the responsibility of ensuring global marine safety via mutually beneficial cooperation withfriends all over the world.
Inside of Foam Filled Solid Fender is filled with environmental protection material-EVA with coating protective layer of polyurea material on outer surface. Polyurea is an new material of adjustable high-elasticity modulus. There are galvanized flange and swivel on the fender two ends. Like pneumatic rubber fender, tyre-chain net protective jacket is also optional spare part to foam filled fender for better anti-collision performance.
►EVA Filled Foam Fender Parameter
| Item Size(DXL) | D (mm) | L (mm) | Compression Value 60% | Energy Absorption (KJ) | Reference Weight (kg) |
| Counter Force (KN) |
| 05OOX1OOOL | 500 | 1000 | 71 | 8 | 34 |
| 06OOX1OOOL | 600 | 1000 | 86 | 12 | 45 |
| 07OOX15OOL | 700 | 1500 | 161 | 27 | 101 |
| 01OOOX15OOL | 1000 | 1500 | 205 | 49 | 206 |
| 01OOOX2OOOL | 1000 | 2000 | 274 | 64 | 275 |
| 012OOX2OOOL | 1200 | 2000 | 337 | 93 | 405 |
| 012OOX24OOL | 1200 | 2400 | 390 | 110 | 475 |
| 0135OX25OOL | 1350 | 2500 | 463 | 145 | 626 |
| 015OOX3OOOL | 1500 | 3000 | 624 | 216 | 927 |
| 017OOX3OOOL | 1700 | 3000 | 696 | 273 | 1191 |
| 02OOOX35OOL | 2000 | 3500 | 990 | 456 | 1923 |
| 02OOOX4OOOL | 2000 | 4000 | 1110 | 505 | 2298 |
| 022OOX45OOL | 2200 | 4500 | 1396 | 679 | 2992 |
| 025OOX4OOOL | 2500 | 4000 | 1386 | 781 | 3434 |
| 025OOX5OOOL | 2500 | 5000 | 1750 | 985 | 4272 |
| 03OOOX5OOOL | 3000 | 5000 | 2050 | 1410 | 6411 |
| 03OOOX6OOOL | 3000 | 6000 | 2460 | 1695 | 7293 |
| 0 33OOX65OOL | 3300 | 6500 | 2950 | 2245 | 8335 |
| 045OOX9OOOL | 4500 | 9000 | 19650 | 7860 | 21460 |
►EVA Polyurethane Foam Filled Floating Fender Product Advantage
- Good floatability makes the installation site not affected by tidal range.
- Non-pneumatic operation, free from scratch and fiction,seawater corrosion resistance and high salt-alkalia tolerance, longer service life up to 15 years without regular maintenance.
- Higher safety factor, free from explosion risk.
►EVA Polyurethane Foam Filled Floating Fender Application
- Harbors, ships
- gravity wharf and dolphin type quay, especially for wharves with bigger
- tidal range
- STS, STD operation
- Protective fender for bridge pier
- Protecting fender for special military fleet or submarine
- Applied together with other forms of fender like pneumatic rubber fender, hydro pneumatic fender, etc.
►Product exhibition
►EVA Filled Foam Fender service
| Quality is the cornerstone, service is the soul. We continue to provide our customers with stable & reliable quality with a comprehensive system of technical support, meticulous and thoughtful after-sales service to win customers trust and satisfaction. Qingdao Henger Shipping Supplies Co., Ltd provides following services to all customers. |
| 1. 24 hours instant online technical consultation and support. |
| 2. 24 months warranty period(without any artificial damage) and free repairing service within warranty period. |
| 3. lifetime reparing service. |
